Bigger stroke, meet different processing requirements
Design Pen Easily converts and automates work paths for mold slotlines, stitching paths, and positioninglines
Suction:1500W motor power,300x500mm suction area, adaptable to various fabricsand processes.
| Machine type | GT-N105130W | GT-N105150W | GT-N105160W | GT-N105180W | GT-N105200W | GT-N105400W |
| Sewing Range | 1000X1300 | 1000X1500 | 1000X1600 | 1000X1800 | 1000X2000 | 1000X2400 |
| Max Speed | 3800 | 3800 | 3800 | 3800 | 3800 | 3800 |
| Needle gauge | 0.1-20 | 0.1-20 | 0.1-20 | 0.1-20 | 0.1-20 | 0.1-20 |
| Machine needle | DPX5 7-24# | DPX5 7-24# | DPX5 7-24# | DPX5 7-24# | DPX5 7-24# | DPX5 7-24# |
| Hook | 2 times push | 2 times push | 2 times push | 2 times push | 2 times push | 2 times push |
| Pressure | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa |
| Foot liting height | 20 | 20 | 20 | 20 | 20 | 20 |
| Y feeding mode | Timing Belt | Timing Belt | Timing Belt | Timing Belt | Timing Belt | Timing Belt |
| X feeding mode | Timing Belt | Timing Belt | Timing Belt | Timing Belt | Timing Belt | Timing Belt |
| Table open size | 2540X2200 | 2540X3200 | 2540X3700 | 2540X3700 | 2540X4100 | 2540X4800 |
| Package size | 1960X1150X1740 With 130W laser, length: 2180mm | 1960X1150X1740 With 130W laser, length: 2180mm | 1960X1150X1740 With 130W laser, length: 2180mm | 1960X1150X1740 With 130W laser, length: 2180mm | 1960X1150X1740 With 130W laser, length: 2180mm | 1960X1150X1740 With 130W laser, length: 2180mm |
| Gross/net weight | 493 | 514 | 521 | 537 | 562 | 592 |
